5/6″ K Jr. Ironman Combo Gutter Machine

The KWM IronMan 5″ & 6″ K Junior Combo Gutter Machine gives you the flexibility to produce both 5″ and 6″ K-style gutters with a single machine. It’s designed for reliable performance, easy operation, and consistent results on the job.

Like other KWM IronMan gutter machines, the K Junior Combo features a durable polyurethane drive system and chrome-plated steel forming rollers. The polyurethane drive system eliminates the need to load the coil before transporting the machine, helping reduce material waste. It also helps prevent slippage caused by cold weather and condensation, keeping production running smoothly in changing conditions.

Specifications

• Manufacturer: KWM

• Machine Style: K Style

• Packages Available: Yes

• Length: 110″

• Width: 27.5″

• Height: 48″

• Weight: 1,127 lbs

• Shipping Method: Common Carrier

The chrome-plated steel forming rollers are designed to rollform all recommended materials with little to no adjustment. This makes it easier to switch between materials while maintaining consistent gutter quality.

Made in the USA, KWM IronMan machines are built to deliver dependable performance and are backed by a comprehensive warranty: 3 years of parts and labor on mechanical components and 1 year of parts and labor on electrical components.

5″ / 6″ Combo IronMan Jr. vs. 5″ / 6″ Combo IronMan

What’s the Difference?

The IronMan Jr. and Regular IronMan are both designed to produce 5″ and 6″ K-style gutters, but there are some important differences in size, weight, and material capabilities.

Size & Weight

Material Capabilities

The biggest difference between the two machines is the range of steel they can run.

• IronMan Jr.: Does not run 26-gauge or 24-gauge steel. It is designed for aluminum and copper.

• Regular IronMan: Can run both 26-gauge and 24-gauge steel, in addition to other recommended materials.

If you regularly work with steel gutter material, the Regular IronMan provides the broader material capability. If you primarily work with aluminum and copper and want a more compact machine, the IronMan Jr. may better suit your setup.

Warranty

Both machines are backed by:

• 3 years: Parts and labor on mechanical components

• 1 year: Parts and labor on electrical components

Polyurethane Drive System

The polyurethane drive system provides smooth, dependable material handling while making transportation easier.

• Eliminates the need to load the coil before transporting the machine, helping reduce material waste

• Helps prevent slippage caused by cold weather and condensation

Hard Chrome-Plated Steel Forming Rollers

The .002″ hard chrome-plated steel forming rollers are designed for consistent forming and long-term durability.

• Rollform recommended materials with minimal or no adjustment

• Free-floating forming rollers reduce pressure on the material

• Helps produce a more uniform finished product

Electrical & Control System

The IronMan Jr. features convenient controls at both ends of the machine.

• Push-button entry and exit controls

• Safety wiring

• “Jog” feature for precise operation

• 3/4 HP, 110-volt, single-phase motor

• 11-amp motor

Structural Steel Frame

The machine is built with a durable welded tubular steel frame for strength and stability.

Modular Turnstile Upright System & Transfer Bars

The modular turnstile system makes coil handling easier.

• Transfer bars help simplify coil loading

• Modular design allows for additional turnstile uprights and spools

Power

• 3/4 HP

• 110 volts

• Single phase

• 11 amps

• Totally Enclosed Fan Cooled (T.E.F.C.) motor

Dimensions

• Length: 110″ (279.4 cm)

• Height: 48″ (122.0 cm)

• Width: 30.5″ (77.5 cm)

Weight

• Approximately 1,127 lbs. (511.2 kg)

Drive

Powered polyurethane drive rollers operate through a chain-and-sprocket system for smooth and consistent material movement.

Shear

• Front-pull guillotine shear

Production Speed

• Approximately 35 feet per minute

Controls

• Push-button controls at the entry and exit ends

• “Jog” feature for greater control during setup and operation

Recommended Materials

The IronMan Jr. is designed primarily for aluminum and copper gutter materials.

Maximum Coil Width

• 5″ K: 11 3/4″ to 12″

• 6″ K: 15″

Available Options

Customize your IronMan Jr. with available options including:

• Smart Machine with automated length control

• Machine-mount cradles

• Additional run-out support stands

• CE-certified wiring

• Additional turnstile uprights

• Additional spools

• 12-volt DC power

• Trailer riser pad
